Copper tube soft
€8.80*
Diameter:
3mm
The soft copper tube is suitable for all applications in steam model making and for technical model making. The Cu pipe is also suitable for gasoline lines or diesel lines for motorcycles, tractors and vintage cars. The copper tube is very malleable and can be easily bent into narrow radii by hand. Our soft copper pipes are delivered in a ring and are 1000mm long. If you need a 3m long copper pipe in one piece, simply order 3m copper pipe in the desired diameter. In order to keep your waste as low as possible, we always deliver the pipes in one piece in the length you ordered. Matching compression fittings can also be found in our shop.
If you order several meters of a CU pipe diameter, we will always send you the copper pipe in one piece.
The following CU tubes and copper tubes in a ring are available:
3mm x 0.5mm soft copper tube
4mm x 0.5mm soft copper tube
5mm x 0.5mm soft copper tube
6mm x 0.5mm soft copper tube
6mm x 1.0mm soft copper tube
8mm x 1.0mm soft copper tube
10mm x 1.0mm soft copper tube
Product number:
5013
Ball bearings for model construction
€2.20*
Size:
3mm x 6mm x 2,5mm
You will find in our shop ball bearings made of steel in different sizes. All ball bearings are offered in the ZZ variant. The double-sided sheet metal disc with gap seal keeps dirt out and guarantees a good smooth running. The ball bearings are very well suited for technical modeling. We use the miniature ball bearings for flame eaters, steam engines and Stirling engines as they are particularly easy to move. Most of the offered ball bearings have a small cross-section to keep the installation dimension as low as possible.
The following ball bearings are available:
Inner diameter
outer diameter
width
ball bearings 63 ZZ
3mm
6mm
2,5mm
ball bearings 106 ZZ
6mm
10mm
3mm
ball bearings 688 ZZ
8mm
16mm
5mm
ball bearings 6700 ZZ
10mm
15mm
4mm
ball bearings 61800 ZZ
10mm
19mm
5mm
Product number:
5183
Variants from €1.80*
Clamping ring
€0.50*
Diameter pipe connection:
für 4mm Rohr
You can find replacement clamping rings here. Since the clamping rings cannot be used again after use, you can order replacement clamping rings for our compression ring fittings here in the shop. The clamping rings are made of brass MS 58.
The following clamping rings are available:
Clamping ring for 4 mm pipe
Clamping ring for 5 mm pipe
Clamping ring for 6 mm pipe
Clamping ring for 8 mm pipe
Clamping ring for 10 mm pipe
Suitable Copper pipe or Brass tube for the compression fitting can be found under the link.
Product number:
7271
Grafi-sil valve balls
€2.60*
Diameter:
4mm
Grafi-sil valve balls are made of a special silicone rubber. The valve balls ensure 100% tightness in steam model construction with their check valves, feed water pumps and injectors, even when the ball sockets are removed or dirty. They can be used in steam, water and oil pipes and are absolutely noise-free.
The following valve ball diameters are available:
4mm Grafi-sil valve balls
5mm Grafi-sil valve balls
6mm Grafi-sil valve balls
8mm Grafi-sil valve balls
10mm Grafi-sil valve balls
12.7mm Grafi-sil valve balls
15,2mm Grafi-sil valve balls
You can of course also retrofit the Grafi-sil balls into your existing components. The maximum ball diameter must always be selected. Sufficient is already 0.3mm distance between ball and armature diameter. The graphi-sil spheres can be used up to a temperature of 400 ° C. We use the Grafi-sil spheres, among other things, as outlet valve balls for our flame eaters.
We offer you a sample set with 2 balls of each size - with a price advantage of 20% !!!
2x4mm / 2x5mm / 2x6mm / 2x8mm
Whoever has used Grafi-sil balls does not take anything else!
!!! Grafi-sil valve balls are also used in machine and plant construction !!!
Product number:
1274
Plaast polymer plastic 1kg
€30.40*
Plaast or even polymorph is a polymer plastic (polycaprolactone) with remarkable properties that can be used for model making great. The plastic is already soft and easily deformable at 60 ° C. Place the granules in max. 65 ° C warm water. As soon as the granulate has become completely transparent, it can be taken out of the water and deformed by hand. After cooling completely, the plastic is hard but not brittle. It can be drilled or cut with a sharp knife.
Plaast is excellently suited for parts. Castings. It is even possible to reprint placards. A greasing of the mold prevents sticking together. Even multi-part forms are no problem. Of course you can also model Plaast with your hand and shape it.
The polymorph plastic can be repeatedly heated and deformed. Plaast is varnishable.
Plaast does not contain any toxic ingredients !!!
You receive from us a bag with 1 kg plastic granulate
Here you will find instructions on how Plaast Polymorph plastic can be used in modeling.
Plaast Polymorph a plastic moldable from 60 ° C
Product number:
5250
Brass balls
€1.80*
Diameter:
8mm
The brass balls have a metric thread. The tapped hole in the balls is not through, it is a blind hole. The brass balls are suitable for the weight of a centrifugal controller on a steam engine or on a Stirling engine. The brass balls can also be used excellently as decorative elements in model construction or crafts, for example as rehling or railings. The balls can be polish very well on high gloss.
These brass ball diameters are available:
Brass ball 8mm diameter M3 thread
Brass ball 10mm diameter M3 thread
Brass ball 12mm diameter M3 thread
Brass ball 16mm diameter M4 thread
Product number:
5268
Model screws
€5.90*
Model screws:
M2x5
Here you will find model construction screws in various diameters and lengths made of brass. A model bucket with a hex head has a smaller key width and a higher head compared to standard hex head screws. With model screws, you can give your steam engine, Stirling engine or Flammenfresser an authentic appearance. Since the screws used at the time of steam engines or station heaters were similar in proportions. In addition, the smaller heads consume less space on your model machine and they can be placed closer. We recommend that you use our Micro plug to mount the model screws. One packaging unit includes 25 model hexagon bolts.
The following model screws are available at any time.
Model building screw brass SW. 3mm M2x5mm / head height 2 mm
Model building screw brass SW. 3mm M2x6mm / head height 2 mm
Model building screw brass SW. 3mm M2x10mm / head height 2 mm
Model building screw brass SW. 4mm M3x8mm / head height 1.7 mm
Model building screw brass SW. 4mm M3x15mm / head height 2,5 mm
Price per 25 pieces in EUR.
Product number:
4051
Abil N sealing material of Elring
€3.10*
The Abil N sealing material of Elring is a cellulose-based sealing paper with an NBR binder. It is suitable for sealing cylinder heads in combustion engines or cylinder covers in steam engines or Stirling engines. Abil can be used to seal against cooling water, oils, fuels and steam. If you want to use the sealing paper to seal steam or air, oil the finished seal well. With this material you can make your own seal. The 0.5mm thick sealing material can be cut perfectly with scissors, perforated iron or knife.
Measurements Abil N sealing paper from Elring:
250mm x 210mm x 0.5mm
Characteristics Abil N sealing paper from Elring:
Color dark gray
Temperature resistant up to 120 ° C (Durable)
Short-term temperature-resistant up to 150 °
Pressure resistant up to 10 bar
Resistant to air, oil, grease, fuel, water and radiator protection
Application:
For seals on housing covers, motors, gearboxes, valve covers or oil pans,
Pneumatic or hydraulic systems.
Both in model making, vintage restoration, crafts or industry
Product number:
3558
Silver steel 115 Cr V3
€3.20*
Diameter material:
3mm
115 Cr V3 Silver steel round material is suitable for the production of shafts, piston rods or for the construction of crankshafts for steam engines and Stirling engines in model construction. The silver steel is hardenable and can thus also be used for heavily stressed tools, for example punch punches. We supply the 115 Cr V3 silver steel in 300mm sections. The silver bars are well suited for running in ball bearings.
Features 115 Cr V3 silver steel
Material No. 1.2210
bright drawn
wear-resistant tool steel (hardenable)
The orderable sections are 300mm long.
Product number:
5043
Schott Duran test tube
€3.40*
Diameter:
10mm
Very thick-walled test tubes made of Duranglas for the construction of Stirling engines or similar applications in technical model construction. The Schott Duran test tubes are mechanically very resistant. Excellent resistance to temperature changes means that you can also use the test tubes as a displacement cylinder for a Stirling engine without worrying that the glass will burst. You can cut the test tubes with our diamond cutting discs. Below you will find a tutorial video.
The test tubes are also suitable for laboratory and medical applications.
We carry the Duran test tubes in these different sizes:
Schott Duran test tube 10mm x 100mm 5ml (actual size: 9,5mm diameter / 100mm long / inside 7,8mm
Schott Duran test tube 12mm x 100mm 8ml (actual size: 11,5mm diameter / 100mm long / inside 9,8mm
Schott Duran test tube 16mm x 130mm 17ml (actual size: 15,5mm diameter / 130mm long / inside 13,5mm (Stirling engine Laura)
Schott Duran Test tube 18mm x 180mm 32ml (actual size: 17,5mm diameter / 180mm long / inside 15,4mm (Stirling engine Rufus)
Schott Duran Test tube 25mm x 150mm 55ml (actual size: 24,5mm diameter / 150mm long / inside 22,3mm
Schott Duran test tube 30mm x 200mm 100ml (actual size: 29,5mm diameter / 200mm long / inside 27,2mm
The test tubes available from Schott are made of Duranglas. All test tubes have a flanged edge and a wall thickness of 1.0mm - 1.2mm. Please note that the test tubes do not have the dimensions specified by the manufacturer, but a tolerance of + - 0,5mm. Please note the actual dimensions given by us.
Product number:
41610
Coupling nut
€1.00*
Diameter pipe connection:
für 4mm Rohr
Here you can also order union nuts for compression fittings individually. You can of course use the union nut as a spare part for our compression fittings but of course you can also use it for your own fittings.
The union nuts are made of brass MS 58.
The following union nuts are available:
Coupling nut with internal thread M8x1 / for 4mm pipe
Coupling nut with internal thread M10x1 / for 5mm pipe
Coupling nut with internal thread M10x1 / for 6mm pipe
Coupling nut with internal thread M12x1 / For 8mm pipe
Coupling nut with internal thread M16x1.5 / for 10mm pipe
Matching Copper pipe or Brass tube for the compression fitting can be found under the link.
Product number:
7261
Cylinder tube
€14.10*
Diameter material:
25mm
This tube is a hydraulic cylinder tube. The inside of the tube is very dimensionally stable and wear-resistant. The cylinder tube is suitable as a cylinder sleeve for an internal combustion engine or flame eater. We also use this cylinder tube in our models. We use it for the combustion engine Karl, Stirling engine "Big Laura" and the Flame Eater Jarne. Due to its high wear resistance, the tube has proven itself as a cylinder sleeve for us.
Dimensions of hydraulic cylinder tube 25mm:
Outer diameter: 35mm
Inner diameter: 25mm
Length: 83mm
Material: St52
Suitable Piston rings for this cylinder tube can be found here
Dimensions of hydraulic cylinder tube 30mm:
Outer diameter: 40mm
Inner diameter: 30mm
Length: 86mm
Material: St52
Dimensions of hydraulic cylinder tube 40mm:
Outer diameter: 50mm
Inner diameter: 40mm
Length: 117mm
Material: St52
Dimensions of hydraulic cylinder tube 50mm:
Outer diameter: 60mm
Inner diameter: 50mm
Length: 142mm
Material: St52
Product number:
5300
Hard copper tube Sf-Cu
€11.10*
Diameter:
2mm
The hard copper tube Sf-Cu is suitable for all applications in steam model construction and for technical model construction. In contrast to the soft copper tube, this copper tube is delivered straight in the bar. If you want to install a straight line, we recommend using this copper pipe. It is suitable for steam lines, fuel lines and cooling water pipes. If the copper tube should be bent once you can burn it with the burner before, afterwards it can bend excellent. The copper tube hard can be easily soldered and brazed. For brazing, we recommend our AG-55 silver braze bars.
Matching flanges and fittings for model building you here.
The CU pipe is supplied as a straight piece
1 Packing unit consists of 3x 330mm long bars. Total length 1000mm
The following copper tubes are available:
2mm x 0.3mm round tube
3mm x 0.5mm round tube
4mm x 0.5mm round tube
5mm x 0.5mm round tube
6mm x 0.5mm round tube
8mm x 1mm round tube
If you need brass pipes, click here (brass pipe Ms63)
Product number:
5022
Variants from €9.50*
Pressure springs stainless steel
€3.80*
Compression springs:
3,15 x 0,2 x 8
Our pressure springs made of stainless steel can be ordered in various sizes and diameters. You get the springs in packing units of 5pcs. Since the dimensions of the compression springs are particularly small, they are ideally suited for use in model construction. We use the springs in various models. For example, as a valve spring in the internal combustion engine "Karl". We have also used the pressure springs as a pressure spring for a flame damper slide. In addition, the compression springs are also suitable as twist protection for nozzle needles of model building carburetors or for the needles of droplets. All springs are made of stainless 1.4310 stainless steel spring steel wire.
In addition, we offer you a pressure spring probeset in which of each spring 2 pieces are included. With the Probeset, you are prepared for many applications in model construction.
Da = Outside diameter
Di = inside diameter
Dd = diameter of spring wire
Aw = distance windings
L = total length
Da
Di
Dd
Aw
L
pressure springs
3,15mm
2,75mm
0,2mm
1,2mm
8mm
pressure springs
4,7mm
4,2mm
0,25mm
1,4mm
8mm
pressure springs
4,3mm
3,7mm
0,3mm
2,3mm
8,5mm
pressure springs
4,0mm
3,3mm
0,4mm
1,5mm
20mm
pressure springs
4,4mm
3,4m
0,5mm
1,8mm
20mm
Product number:
5291
Silicone tube
€2.20*
Inner end / wall thickness:
2mm / 1mm
Our silicone tube is highly flexible and has a temperature range -60 ° C to + 180 ° C and is slightly cloudy. The silicone hose can be used to connect a steam engine. The tubes are ideally suited for supplying your steam engines with compressed air or steam in the workshop, on model constructions or model building exhibitions. Silicone tube are also suitable as fuel lines for model-built motors due to their good resistance to chemicals. Another advantage of the silicone tubing is that it is transparent and you can always see if, for example, fuel or alcohol is in the line.
The following silicone hoses are available:
Innen
Außen
Wandstärke
silicone tube:
2mm
4mm
1mm
silicone tube:
3mm
5mm
1mm
silicone tube:
3mm
6mm
1,5mm
silicone tube:
4mm
6mm
1mm
silicone tube:
4mm
8mm
2mm
For each selected piece you get 1m silicone tube.We deliver you the ordered length of silicone tube always in the piece
Product number:
70721
Stainless steel 1.4305
€2.90*
Diameter material:
3mm
This stainless steel 1.4305 is very easy to cut and is ideal for turning, milling, drilling and tapping. This stainless steel can be used well everywhere in model construction. as a stainless piston rod for a model steam engine. However, the round stainless steel material is also suitable for use as a crankshaft with Stirling engines or flame eaters.
We supply the 1.4305 stainless steel in 300mm sections.
Stainless Steel Round Material Stainless 1.4305 blank.
machines quality
Strength: F60
Product number:
5073
Round belt 2mm rough
€3.50*
Round belt for driving drive models or small machines. The drive belt has a diameter of 2 mm and a roughened surface. It is made of highly flexible PU material. You can cut the strap to the desired length and then weld it by heating it (lighter or small blowtorch) and pressing it together. These flexible but still very stable straps are ideal for model making.
The drive belt is delivered as a 1 m piece.
Welding the drive belt is very easy. Use either a candle or a small burner with a soft flame. Hold both ends of the strap to the flame until the plastic begins to melt. Then press the two ends of the strap lightly against each other. After the material has cooled, the excess can be removed with a scalpel or small side cutters.
Product number:
4360
Compression fittings
€3.70*
Diameter pipe connection:
für 4mm Rohr
With these compression fittings you can connect two copper pipes or brass pipes together without soldering. A compression fitting consists of a base body, two cutting rings and two union nuts. All parts of the compression fitting are made of brass. The compression fittings can be used in both pneumatics and hydraulics. These screw connections are also used to connect lubrication lines, gasoline lines, gas lines, supply steam lines or exhaust steam lines. The compression fittings are also used in trade and industry. There are even many areas of application in model making.
To crimp a pipe, the union nut is first pushed over the pipe. The cutting ring is then also pushed onto the pipe. Now the pipe can be inserted into the base body and the union nut is tightened using a wrench. When the union nut is tightened, the clamping ring is compressed so tightly that it can no longer be removed from the pipe without being destroyed.
The following compression fittings are available:
Straight compression fitting for 4 mm pipe / internal thread union nut M8x1
Straight compression fitting for 5 mm pipe / internal thread union nut M10x1
Straight compression fitting for 6 mm pipe / internal thread union nut M10x1
Straight compression fitting for 8 mm pipe / internal thread union nut M12x1
Straight compression fitting for 10 mm pipe / internal thread union nut M6x1.5
Suitable Copper pipe or Brass tube for the compression fitting can be found under the link.
Product number:
7231
Quick coupling Nw 2.7
€6.80*
NW 2,7:
M5 aussen
The mini quick coupling Nw 2.7 is a great addition to your hobby workshop. With the quick couplings you can test run your steam engine with compressed air quickly and without loss of pressure. The couplings are ideal for supplying your steam engines with compressed air at model building fairs or model building exhibitions. The quick couplings can be easily opened with one hand, even when the line is under pressure. The one-hand quick-release coupling has extremely small dimensions with a large passage.
Normally, the areas of application for quick couplings are: medical technology, dental technology, measurement and control technology, smaller compressed air tools, chemistry, laboratory technology, analysis technology, mini pneumatics and mechanical engineering. Matching insert sleeves can be found here.
Properties of the quick-release couplings Nw 2.7
Operating pressure: 0 - 35 bar
Medium and ambient temperature: -20 °C to +100 °C
Housing, sleeve and valve body: brass
Spring, snap ring, balls: stainless steel
Sealing material: Perbunan
Flow rate at 6 bar: 165 l/min
Variants of the quick-release couplings Nw 2.7:
Quick-connect couplings NW 2.7 - M 5 outside
Quick-release couplings NW 2.7 - M 5 inside
Quick coupling couplings NW 2.7 - grommet LW 3
Quick coupling couplings NW 2.7 - grommet LW 4
Quick coupling couplings NW 2.7 - hose connection with union nut 3mm x 5mm
Quick coupling couplings NW 2.7 - hose connection with union nut 4mm x 6mm
Quick-connection couplings NW 2.7 - bulkhead screw connection grommet LW 3 (Can be screwed into a hole in sheets or housings)
Quick-connection couplings NW 2.7 - bulkhead screw connection grommet LW 4 (Can be screwed into a hole in sheets or housings)
Product number:
7021
Brass Ms58 flat material
€14.90*
Strength:
50mm x 2mm
Brass Ms58 flat material is a very good machinable material. Brass is probably the most widely used material in technical modeling. Which is certainly due to the fact that it can be worked very well. It can be milled, turned, drilled, brazed and softened. Many Stirling engines, steam engines and flame eaters in technical model construction are mainly made of MS58 brass. You can order brass flat material in different thicknesses from 2mm to 6mm here at the Bengs Modellbau Shop.
Flat Material Brass Quality: Ms 58 (drilling and turning quality)
Strength F45-50
Flat material 50mm wide
Length 300mm
Product number:
5212
Variants from €3.60*
Flywheel 140mm
€38.00*
The flywheel for flame eaters, Stirling engines or steam engines. The flywheels are produced in the lost wax process. The advantage of this casting process is that the casting has a very high quality and dimensional stability. Blisters and hard spots are excluded in the lost wax process. The flywheel has a raw diameter of 141mm. The angles are already polished. The flywheel is cleaned and sandblasted. The flywheel must still be finished by you on its lathe. It is suitable both for use as a flywheel on a model machine and as a tire for a cannon or a caterpillar.
Dimensions of the flywheels:
Raw diameter: 141mm
Finish diameter: 140mm
Diameter of the scar: 22mm
Width: 19mm
Wide scar: 26mm
Weight: 800g.
Material: cast steel (no gray cast iron)
Product number:
6015
Flywheel 80mm light
€21.20*
This flywheel has an outer diameter of 81mm, it has 12 spokes which are only 2mm thick and 3mm deep. Due to the filigree appearance, it is particularly suitable for Stirling engines and flame eaters. Of course, the flywheels are also suitable as wheels for a motor laffeet or a cannon-booster. The flywheels are produced in the lost wax process. The advantage of this casting process is that the casting has a very high quality and dimensional stability. Blisters are excluded in the lost wax process. The sprue has already been polished. The flywheel is cleaned and sandblasted.
Dimensions of the 80mm flywheel:
Raw diameter: 81mm
Finish diameter: 80mm
Width on the hoop: 15mm
Width at the waist: 17mm
Diameter of the collar: 13mm
Weight: 180g
Material: Cast steel (no gray cast iron)
Product number:
6016
Threaded rod DIN 975
€3.40*
Material:
Brass
|
Thread:
M2
The threaded rods are available in brass Ms58 or stainless steel A2 in the diameters M2, M3, M4, M5 and M6. They can be used either as stud bolts, adjusting spindle drive shaft or as screwdrivers.
A packing unit contains 2 threaded rods 250mm long.
Threaded rod DIN 975 / brass M2
Threaded rod DIN 975 / brass M3
Threaded rod DIN 975 / brass M4
Threaded rod DIN 975 / brass M5
Threaded rod DIN 975 / brass M6
Threaded rod DIN 975 / stainless steel M2
Threaded rod DIN 975 / stainless steel M3
Threaded rod DIN 975 / stainless steel M4
Threaded rod DIN 975 / stainless steel M5
Threaded rod DIN 975 / stainless steel M6
Product number:
4132
Cast iron round material
€21.60*
Diameter material:
30mm
Cast iron with lamellar graphite. The surface is peeled on the gray cast iron bars. The round bars are a little over-sized. You can also make a 30mm piston with a 30mm diameter. The material is suitable both for the production of pistons or cylindrical sleeves for model-built motors as well as for the production of plain bearing bushes. We use this material for the pistons at the station "Karl". The round material can be perfectly machined on the lathe and on the milling machine and has excellent running characteristics.
All round bars are 300mm long.
Product number:
5171
